NPT,SAE,PT thread for all parts is availableCategory Details Subplate Types PH3B12LL and PH3B38 Base Plate Type PH3B12LL and PH3B38 Subplate, A-B-P-T Side Ports 1/2" G; Weight = 3 kg Ordering Code (Subplate) PHS – B – 12 – LL (side ports) Hydraulic Symbol As shown in diagram CETOP Size CETOP 3
Pehel/PHS3B38/High Pressure NPT, SAE Thread Subplate Block/Material Carbon Steel, Aluminum Available
PEHEL Hydraulic Model: PHS3B38
QTY:
- 1. Subplate, A-B-P-T side ports 1/2”G; weigh= 3 kg
2. Subplate, A-B side ports, P-T ports on side and rear, with relief valve.(RV) weight= 3 kg
3. up to 8 stations
4. NPT, SAE, PT thread for all parts is available
5. Scientific design and precise manufacturing Material: Carbon steel
Brand: Pehel, OEM
Color: Silver Zinc plating
Connector Type: Manifold Block
Thread Type: NPT/SAE
About the item:
1.High Pressure Tolerance: Withstands up to 31.5MPa, suitable for heavy-load hydraulic systems.
2.One-Stop Customization: Threads, Coatings & Port Sizes
3.Precision-Machined Manifold for Complex Hydraulic Circuits
