PART NO. THREAD E HOSE BORE TUBE O.D. O RING DIMENSIONS DN DASH A C H S2 20541-14-04T M14X1.5 6 04 6 O04.0X1.5 44 2 21 17 20541-16-04T M16X1.5 6 04 8 O06.0X1.5 44 2 21 19 20541-18-04T M18X1.5 6 04 10 O08.0X1.5 44 2 21 22 20541-18-06T M18X1.5 10 06 10 O08.0X1.5 48.5 2 23 22 20541-20-06T M20X1.5 10 06 12 O10.0X1.5 50 4 24.5 24 20541-22-08T M22X1.5 12 08 14 O11.0X2.0 55.5 3 26 27 20541-24-08T M24X1.5 12 08 16 O13.0X2.0 56.5 3 27 30 20541-30-10T M30X2 16 10 20 O16.3X2.0 63.5 5 31 36 20541-36-12T M36X2 20 12 25 O20.3X2.4 73.5 3 34 46 20541-42-16T M42X2 25 16 30 O25.3X2.4 92.2 5 37 50 20541-52-24T M52X2 40 24 38 O33.3X2.4 116 6.5 45 60 NOTE:1.For use with braided hoses. 2.If use with spiral hoses,hose fitting series number is 20542-XX-XX。
Pehel/20541-T/45° Elbow Metric Female 24°cone O-ring H.T. Hydraulic Hose Fitting
PEHEL Hydraulic Model: P20541-T
QTY:
45 Elbow Metric Female 24º Multiseal H. T. Hose Fitting 20541
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: Elbow
Thread Type: Metric 24° Cone H.T.
About the item:
1.Full through-bore design maintains consistent internal flow diameter, avoiding flow restriction that causes system heat rise and efficiency loss.
2.Zinc-plated carbon steel body with salt spray resistance up to 240 hours, effectively preventing corrosion in outdoor and humid working environments.3.Interchangeable with ISO 8434 standard counterparts, no custom modification required for direct replacement in existing hydraulic systems.
