PART NO. THREAD DIMENSIONS E F A B L S1 S2 2BA-02 G1/8"X28 G1/8"X28 10 2 28.5 14 14 2BA-04 G1/4"X19 G1/4"X19 12 4 30.5 19 19 2BA-06 G3/8"X19 G3/8"X19 13.5 5 35 22 22 2BA-08 G1/2"X14 G1/2"X14 16 6 41.5 27 27 2BA-10 G5/8"X14 G5/8"X14 17.5 8 43.5 30 30 2BA-12 G3/4"X14 G3/4"X14 18.5 9 46.5 32 32 2BA-16 G1"X11 G1"X11 20.5 10.5 51 41 41 2BA-20 G1.1/4"X11 G1.1/4"X11 20.5 10 55 50 50 2BA-24 G1.1/2"X11 G1.1/2"X11 23 11 59 55 55 2BA-32 G2"X11 G2"X11 25.5 15 65.5 70 70
Pehel/2BA/ISO Certified Male BSP 60 Cone Seal-Female BSP Multiseal Straight Connector
PEHEL Hydraulic Model: 2BA
QTY:
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver Zinc plating
Connector Type: Straight
Thread Type: BSP
About the item:
1.Full through-bore design maintains consistent internal flow diameter, avoiding flow restriction that causes system heat rise and efficiency loss.
2.Precision-machined straight hydraulic adapters with concentric thread alignment, eliminating flow turbulence and pressure drop in high-flow hydraulic loops.
3.Interchangeable with ISO 8434 standard counterparts, no custom modification required for direct replacement in existing hydraulic systems.
