PART NO. THREAD TUBE O.D. DIMENSIONS MPa E F D1 B l1 L1 S1 S2 31.5 L 1CM-12-10 M12X1.5 M10X1 6 8 8.5 23 14 14 1CM-14-12 M14X1.5 M12X1.5 8 12 10 25 17 17 1CM-14-18 M14X1.5 M18X1.5 8 12 11.5 26 24 17 1CM-16-14 M16X1.5 M14X1.5 10 12 11 26 19 19 1CM-16 M16X1.5 M16X1.5 10 12 12 27 22 19 1CM-16-18 M16X1.5 M18X1.5 10 12 12.5 27 24 19 1CM-16-22 M16X1.5 M22X1.5 10 14 14 29 27 19 1CM-18-14 M18X1.5 M14X1.5 12 12 11 26 19 22 1CM-18-16 M18X1.5 M16X1.5 12 12 12 27 22 22 1CM-18 M18X1.5 M18X1.5 12 12 12.5 27 24 22 1CM-18-22 M18X1.5 M22X1.5 12 14 14 29 27 22 1CM-22-16 M22X1.5 M16X1.5 15 12 13 28 24 27 1CM-22-18 M22X1.5 M18X1.5 15 12 13.5 29 24 27 1CM-22 M22X1.5 M22X1.5 15 14 15 30 27 27 1CM-26-18 M26X1.5 M18X1.5 18 12 14 30 27 32 1CM-26-22 M26X1.5 M22X1.5 18 14 14.5 31 27 32 1CM-30-22 M30X2 M22X1.5 22 14 16.5 33 32 36 16 L 1CM-30-26 M30X2 M26X1.5 22 16 16.5 33 32 36 1CM-30-27 M30X2 M27X1.5 22 16 18.5 35 32 36 1CM-36-33 M36X2 M33X2 28 18 17.5 34 41 41 1CM-45-42 M45X2 M42X2 35 20 17.5 39 50 50 1CM-52-48 M52X2 M48X2 42 22 19 42 55 60 1DM-14-12 M14X1.5 M12X1.5 6 12 13 28 17 17 63S 1DM-16-14 M16X1.5 M14X1.5 8 12 15 30 19 19 1DM-18-16 M18X1.5 M16X1.5 10 12 15 31 22 22 1DM-20-18 M20X1.5 M18X1.5 12 12 17 33 24 24 1DM-20-22 M20X1.5 M22X1.5 12 14 17.5 34 27 24 1DM-22-20 M22X1.5 M20X1.5 14 14 19 37 27 27 1DM-24-18 M24X1.5 M18X1.5 16 12 18 36 27 30 40S 1DM-24-22 M24X1.5 M22X1.5 16 14 18.5 37 27 30 1DM-30-27 M30X2 M27X2 20 16 20.5 42 32 36 1DM-36-33 M36X2 M33X2 25 18 23 47 41 46 1DM-42 M42X2 M42X2 30 20 23.5 50 50 50 25 S 1DM-52-48 M52X2 M48X2 38 22 57 55 60 Note��In case if you are interested to order the adapter in complete set with cutting ring
Leakproof Metric Hydraulic Stud Ends Metric Thread 60 Cone Sealing or Bonded Seal Structure
PEHEL Hydraulic Model: 1CM-1DM
QTY:
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type:
Thread Type:
- About the item:
- 1.These metric thread stud ends support two sealing modes: 60 cone sealing and bonded seal, matching different hydraulic equipment requirements.
- 2.Made of carbon steel and stainless steel, this metric hydraulic stud fitting delivers stable high-pressure resistance for heavy-duty hydraulic pipelines.
- 3.Silver zinc plating surface of the dual seal metric hydraulic stud ends offers excellent rust resistance and extends long-term service life.
- 4.Pehel brand supply and full OEM customization service are available for metric thread stud ends to meet large-volume wholesale orders.
- 5.Precisely machined metric thread on the bonded seal metric hydraulic stud ends ensures tight assembly and avoids medium leakage.
