PART NO
THREAD E
HOSE BORE
TUBE O.D.
DIMENSIONS
DN
DASH
C
S2
H
P20441-14-04T
M14X1.5
6
4
8
2
19
27
P20441-16-04T
M16X1.5
6
4
10
2
22
27.3
P20441-16-05T
M16X1.5
8
5
10
2
22
28.2
P20441-16-06
M16X1.5
10
6
10
2
22
29.2
P20441-18-06T
M18X1.5
10
6
12
2.5
24
29.2
P20441-22-08T
M22X1.5
12
8
15
2.5
27
33.2
P20441-26-10T
M26X1.5
16
10
18
2.5
32
35.9
P20441-27-10T
M27X1.5
16
10
18
2.5
32
35.9
P20441-30-12T
M30X2
20
12
22
4
36
41.7
P20441-36-16T
M36X2
25
16
28
4
41
42.8
P20441-30-10T
M30X2
16
10
22
4
36
30.3
P20441-45-20T
M45X2
32
20
35
5
55
40.8
P20441-52-24T
M52X2
40
24
42
5.5
60
45.8
OEM union type female metric threaded 45 degree elbow one piece hydraulic crimp hose tube fittings
PEHEL Hydraulic Model: 20441PKAST
QTY:
Hydraulic Metric 45deg Light Series Hose Fitting
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type: 45 Degree Union Elbow One Piece Crimp Hose Connector
Thread Type: Female Metric Thread
- 1.This one piece 45° female metric thread union crimp hydraulic hose fitting delivers stable connection without leakage under high pressure.
- 2.Standard female metric thread design makes this union crimp fitting widely match most industrial hydraulic rubber hoses.
- 3.Integrated one-piece structure of 45 degree metric female crimp hose fitting improves tensile strength and avoids split failure.
- 4.Zinc silver plating surface on Pehel hydraulic crimp fitting offers rust resistance for long-term outdoor hydraulic equipment use.
- 5.Available in carbon steel & stainless steel, this union type metric female crimp elbow meets OEM custom hydraulic fitting demands.
