PART NO. THREAD DIMENSIONS F B D L S2 2WA-08-04 G1/4"X19 4 8 40 19 2WA-10-04 G1/4"X19 4 10 35 19 2WA-10-06 G3/8"X19 5 10 30 22 2WA-13-04 G1/4"X19 4 13 40 19 2WA-12-06 G3/8"X19 5 12 40 22 2WA-14-06 G3/8"X19 5 14 40 22 2WA-16-08 G1/2"X14 6 16 45 27 2WA-17-06 G3/8"X19 5 17 45 22 2WA-18-08 G1/2"X14 6 18 45 27 2WA-21-08 G1/2"X14 6 21 50 27 2WA-21-12 G3/4"X14 9 21 50 32 2WA-22-12 G3/4"X14 9 22 50 32 2WA-27-12 G3/4"X14 9 27 50 32 2WA-27-16 G1"X11 10.5 27 50 41 2WA-28-16 G1"X11 10.5 28 50 41 2WA-33-16 G1"X11 10.5 33 55 41 2WA-34-20 G1.1/4"X11 10 34 55 50 2WA-42-20 G1.1/4"X11 10 42 55 50 2WA-42-32 G2"X11 15 42 55 70 2WA-50-32 G2"X11 15 50 55 70 2WA-57-32 G2"X11 15 57 60 70
Pehel | Butt‑Weld Tube BSP Female Multiseal Hydraulic Fitting
PEHEL Hydraulic Model: 2WA
QTY:
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type:
Thread Type:
About the item:
- 1.Carbon steel and stainless steel material options fit various hydraulic working conditions.
- 2.Silver zinc‑plated surface improves corrosion resistance for this BSP female multiseal fitting.
- 3.Precise butt‑weld tube end ensures smooth welding connection with matching hydraulic tubes.
- 4.Accurate BSP female thread machining guarantees quick assembly and stable connection.
- 5.Offer Pehel standard products and OEM service for custom butt weld hydraulic fitting requirements.
