PART NO.
FLANGE SIZE
HOSE BORE
DIMENSIONS
DN
DASH
A
C
D
H
L
87342-08-08
1/2"
12
8
58.5
30.2
23.9
23.3
7
87342-12-08
3/4"
12
8
59
38.1
31.7
24
7
87342-12-10
3/4"
16
10
70
38.1
31.7
25.3
7
87342-12-12
3/4"
20
12
77.3
38.1
31.7
29
7
87342-16-12
1"
20
12
77.3
44.4
38
29
8.2
87342-16-16
1"
25
16
85
44.4
38
29.7
8.2
87342-16-20
1"
32
20
94
44.4
38
34
8.2
87342-20-16
1.1/4"
25
16
85
50.8
43.2
29.7
8.2
87342-20-20
1.1/4"
32
20
94.5
50.8
43.2
33.8
8.2
87342-24-20
1.1/2"
32
20
101
60.3
50.3
37
8.2
87342-24-24
1.1/2"
40
24
110
60.3
50.3
39
8.2
87342-32-24
2"
40
24
110
71.4
62.2
39
9.8
87342-32-32
2"
50
32
141
71.4
62.2
48.3
9.8
NOTE:1.For use with braided hoses. 2.If use with spiral hoses,hose fitting series number is 87341-XX-XX。
Pehel 3000 PSI 45 degree elbow flange hose fittings
PEHEL Hydraulic Model: P87342
QTY:
87342 3000 PSI flange hose fittings 45 degree elbow fitting adapter ferrule flange hydraulic flange
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type:
Thread Type:
About the item:
- 1.87342 3000 PSI flange hose fitting with 45‑degree elbow design optimizes hydraulic hose routing.
- 2.Robust ferrule flange structure delivers reliable pressure resistance for heavy‑duty hydraulic applications.
- 3.Available in carbon steel and stainless steel for different working‑condition requirements.
- 4.Silver zinc‑plated surface improves anti‑corrosion performance of this hydraulic flange adapter.
- 5.Precisely manufactured flange ferrule ensures firm hose assembly and leak‑free operation.
