PART NO.
THREAD E
HOSE BORE
DIMENSIONS
DN
DASH
C
S1
S2
H
Per hundred weight
Weight per case
29691-04-04
G1/4"-19
6
4
8
19
19
38
4.4
250
29691-04-05
G1/4"X19
8
5
8
19
19
41
250
29691-06-06
G3/8"-19
10
6
9
22
22
45.8
8.2
120
29691-08-08
G1/2"-14
12
8
12
27
27
53
14.5
70
29691-10-10
G5/8"X14
16
10
11.5
30
30
61
100
29691-12-12
G3/4"-14
20
12
13.5
32
32
69
30.8
60
29691-16-16
G1"-11
25
16
16
41
41
76.5
30
29691-20-20
G1.1/4"-11
32
20
18.5
50
50
90
20
29691-24-24
G1.1/2"-11
40
24
19
55
55
105
10
90º JIS Gas Female 60º Cone Seat
PEHEL Hydraulic Model: P29691
QTY:
29691 BSP 90° Elbow Female Fittings 60° Cone -JIS B8363
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type:
Thread Type:
About the item:
- 1.This 90‑degree JIS gas female tube connector features precise 60° cone seat for leak‑proof hydraulic sealing.
- 2.Supplied in carbon steel and stainless steel to fit various hydraulic working environments.
- 3.Silver zinc‑plated surface enhances anti‑corrosion performance for this JIS hydraulic tube connector.
- 4.Accurate JIS gas female thread machining ensures quick installation and stable pipe connection.
- 5.90° elbow structure optimizes pipeline layout for limited‑space hydraulic system installations.
