small tube clamp 1and : smaller size clamp
Range of application
Prematic line,vehicle,machine building,metering and controlling equipment,machine tool and cable,hose.
Order code
PTTSP--Small twin tube clamp. polypropyienePTTSN--Small twin tube clamp. polypamide 6
(As required please exchange standard abbreviation "TTSP"in column for "order code")
.jpg)
.jpg)
Clamp size mm O.D
d1/d2inch I.D inch.O.D Order code Size Order code Size L1 L2 B H L4 B2 1 6/6 1/4/1/4 PTTSP-10.6
PTTSP-106.4
PTTSP-10832 18 14.5 13.5 PTS-G1 29 15.5 2 8/8
9.5/9.5
10/10
12/12
12.7/12.71/8/1/8
3/8/3/8
1/2/1/2PTTSP-208
PTTSP-209.5
PTTSP-210
PTTSP-212
PTTSP-212.741 22 14.5 18.5 PTS-G2 40 16.5 3 10/10
12/12
12.7/12.7
13.5/13.5
14/14
15/15
16/161/8/1/8
1/4/1/4
1/2/1/2
5/8/5/8
PTTSP-310
PTTSP-312
PTTSP-312.7
PTTSP-313.5
PTTSP-314
PTTSP-315
PTTSP-31654 30 14.5 23.5 PTS-G3 49.5 16 4 14/14
15/15
16/16
17.2/17.2
18/18
19/19
20/20
21.3/21.3
22/223/8/3/8
1/2/1/2
5/8/5/8
3/4/3/4
PTTSP-414
PTTSP-415
PTTSP-416
PTTSP-417.2
PTTSP-418
PTTSP-419
PTTSP-420
PTTSP-421.3
PTTSP-42270 38 14.5 30.5 PTS-G4 62.5 16
Pehel/PTTSP/High Quality Small Tube Clamp DIN3015/All Sizes Available
PEHEL Hydraulic Model: Small Tube Clamp PTTSP
QTY:
- small tube clamp 1and : smaller size clamp from small to big size, 3 material can be choosed for clamp body
Material: Can be chosen
Brand: Pehel, OEM
Color: Can be chosen
Connector Type: Tube clamp
Thread Type: Clamp
About the item:
1.Strictly manufactured per DIN 3015 standard, guarantees full interchangeability with global mainstream pipeline systems
2.Precision dimensional control ensures perfect fit for corresponding small tubes without loose or misalignment issues
3.Certified raw material meets industrial safety requirements, no harmful substances released under long-term working conditions
4.Full size coverage fits various small tube specifications, no extra modification needed for quick on-site installation
