PEHEL | PHS3A14L Hydraulic Subplate, A-B-P-T Ports 1/4" G with Back or Side Configuration

PEHEL Hydraulic Model: PHS3A14L

• 1. Model NO.: PHS3A14L
  2. Subplate, A-B-P-T on back, weigh 1 kg
      Subplate, A-B-P-T on side 1/4”G, weigh 1 kg
  3. NPT, SAE, PT thread for all parts is available
  4. Superior in quality and competitive in price
  5. Scientific design and precise manufacturing


• • Model No.: PHS3A14L

  • Type: Hydraulic Valve Subplate

  • Port Configuration: A-B-P-T

  • Port Position: Back or Side

  • Port Thread: 1/4" G (customizable to NPT, SAE, PT)

  • Weight: 1 kg

  • Material: Carbon steel

  • Brand: PEHEL, OEM

  • Surface Treatment: Anti-rust coated




    1. 1.PHS3A14L hydraulic subplate designed for mounting directional control valves, featuring A-B-P-T port configuration.

    2. 2.Available in two port position options: all four ports on the back face, or all four ports on the side face with 1/4" G threads.

    3. 3.Weighs 1 kg, offering a compact and lightweight solution for valve mounting applications.

    4. 4.Thread options available in NPT, SAE, and PT to suit different system requirements.

    5. 5.Manufactured from high-strength carbon steel with anti-rust surface treatment for reliable performance.

    6. 6.Scientific design and precise manufacturing ensure leak-free interface between valve and subplate.
