BSPT Male/BSPT Female-P5T-SP

BSPT Male/BSPT Female-P5T-SP

PEHEL Hydraulic Model: P5T-SP

QTY:

  • BSPT Male/BSPT Female-P5T-SP Specification
  • You May Also Like
  • PART NO. THREAD DIMENSIONS
    E F A S1 L
    P5T-02-04 R1/8"-28 Rc1/4"-19 11 19 32.5
    -04-02 R1/4"-19 Rc1/8"-28 14.5 17 22
    -04-06 R1/4"-19 Rc3/8"-19 14.5 22 38
    -06-02 R3/8"-19 Rc1/8"-28 14 19 23
    -06-04 R3/8"-19 Rc1/4"-19 15 19 23
    -06-08 R3/8"-19 Rc1/2"-14 15 27 44
    -08-04 R1/2"-14 Rc1/4"-19 20 24 28
    -08-06 R1/2"-14 Rc3/8"-19 20 24 28
    -08-12 R1/2"-14 Rc3/4"-14 20 36 51
    -12-04 R3/4"-14 Rc1/4"-19 20 30 31
    -12-06 R3/4"-14 Rc3/8"-19 20 30 31
    -12-08 R3/4"-14 Rc1/2"-14 20 30 31
    -12-16 R3/4"-14 Rc 1"-11 20 41 56.5
    -16-04 R 1"-11 Rc1/4"-19 25.5 36 35
    -16-06 R 1"-11 Rc3/8"-19 25.5 36 35
    -16-08 R 1"-11 Rc1/2"-14 25.5 36 35
    -16-12 R 1"-11 Rc3/4"-14 25.5 36 35
    -16-20 R 1"-11 Rc1.1/4"-11 25.5 55 64
    -20-12 R1.1/4"-11 Rc3/4"-14 26.5 46 36
    -20-16 R1.1/4"-11 Rc 1"-11 26.5 46 36
    -24-08 R1.1/2"-11 Rc1/2"-14 26.5 50 39
    -24-12 R1.1/2"-11 Rc3/4"-14 226.5 50 39
    -24-16 R1.1/2"-11 Rc 1"-11 26.5 50 39
    -24-20 R1.1/2"-11 Rc1.1/4"-11 26.5 50 39
    -32-16 R 2"-11 Rc 1"-11 30 65 47
    -32-20 R 2"-11 Rc1.1/4"-11 30 65 45
    -32-24 R 2"-11 Rc1.1/2"-11 30 65 47
