PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH C S2 Per hundred weight Weight per case P16011-04-04 7/16"x20 6 4 9.1 14 1.7 300 P16011-05-04 1/2"x20 6 4 9.1 17 2.3 250 P16011-06-05 9/16"x18 8 5 9.9 17 250 P16011-06-06 9/16"x18 10 6 9.9 17 3.2 200 P16011-08-06 3/4"x16 10 6 11.1 22 5.3 150 P16011-08-08 3/4"x16 12 8 11.1 22 5.8 120 P16011-10-08 7/8"x14 12 8 12.7 27 9.1 100 P16011-10-10 7/8"x14 16 10 12.7 27 9.4 250 P16011-12-10 1.1/16"x12 16 10 15.1 32 13 180 P16011-12-12 1.1/16"x12 20 12 15.1 32 15.4 150 P16011-16-16 1.5/16"x12 25 16 15.1 38 23.8 80
PEHEL / 16011 / Hydraulic Fitting SAE Male With O Ring Short Lead Time
PEHEL Hydraulic Model: P16011
QTY:
Male SAE O-Ring Seal Straight Hose Fitting
Hydraulic Fitting Male SAE With O-Ring Easier To Install
Material: Carbon steel
Surface Treatment: White Zinc Plating
Brand: PEHEL, OEM
Color: Silver
Connector Type: Straight
Thread: SAE
1. PEHE 16011 SAE fitting with O-ring for leak-free hydraulic connections.
2. Carbon steel material with zinc plating ensures superior durability and corrosion resistance.
3. DIN 3865 / ISO 12151-2-compliant design delivers reliable sealing under high pressure and extreme temperatures.
4. Compatible with multiple fluid types, including oil, water, and air.
5. SAE standard with O-ring seal prevents fluid escape in demanding industrial applications.
