TEE Stecko Female

TEE Stecko Female

PEHEL Hydraulic Model: DY

QTY:

  • TEE Stecko Female Specification
  • You May Also Like
  • PART NO. STECKO SIZE DIMENSIONS
    LEFT MIDDLE RIGHT A,C B M1,M3 N1,N3 M2 N2 S1
    DY-04 1/4" 1/4" 1/4" 38 38 15.16 10.03 15.16 10.03 16
    DY-06 3/8" 3/8" 3/8" 42.5 42.5 20.17 14.02 20.17 14.02 22
    DY-08-06-08 1/2" 3/8" 1/2" 46 46 24.16 18.03 20.17 14.02 27
    DY-08 1/2" 1/2" 1/2" 46 46 24.16 18.03 24.16 18.03 27
    DY-08-12-08 1/2" 3/4" 1/2" 51.5 51.5 24.16 18.03 29.16 24.03 36
    DY-12-06-12 3/4" 3/8" 3/4" 51.5 51.5 29.16 24.03 20.17 14.02 36
    DY-12-08-12 3/4" 1/2" 3/4" 51.5 51.5 29.16 24.03 24.16 18.03 36
    DY-12 3/4" 3/4" 3/4" 51.5 51.5 29.16 24.03 29.16 24.03 36
    DY-16-06-16 1" 3/8" 1" 63.5 57.5 39.12 31.01 20.17 14.02 48
    DY-16-08-16 1" 1/2" 1" 63.5 57.5 39.12 31.01 24.16 18.03 48
    DY-16-12-16 1" 3/4" 1" 63.5 57.5 39.12 31.01 29.16 24.03 48
    DY-16 1" 1" 1" 63.5 63.5 39.12 31.01 39.12 31.01 48
    DY-20-12-20 1.1/4" 3/4" 1.1/4" 63.5 57.5 46.15 38.02 29.16 24.03 48
    DY-20-16-20 1.1/4" 1" 1.1/4" 63.5 63.5 46.15 38.02 39.12 31.01 48
    DY-20 1.1/4" 1.1/4" 1.1/4" 63.5 63.5 46.15 38.02 46.15 38.02 48
