PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH A C S1 S2 24211D-04-04 9/16"X18 6 04 29 7.5 19 19 24211D-06-04 11/16"X16 6 04 33.5 9.5 22 22 24211D-06-05 11/16"X16 8 05 33.5 9.5 22 22 24211D-06-06 11/16"X16 10 06 33.5 9.5 22 22 24211D-06-08 11/16"X16 12 08 34 9.5 22 22 24211D-08-06 13/16"X16 10 06 36 11.5 27 27 24211D-08-08 13/16"X16 12 08 36.5 11.5 27 27 24211D-10-08 1"X14 12 08 40.5 12.5 32 32 24211D-10-10 1"X14 16 10 41 12.5 32 32 24211D-10-12 1"X14 20 12 41.5 12.5 32 32 24211D-12-08 1-3/16"X12 12 08 44.5 13 36 36 24211D-12-10 1-3/16"X12 16 10 45 13 36 36 24211D-12-12 1-3/16"X12 20 12 45.5 13 36 36 24211D-12-16 1-3/16"X12 25 16 47.2 13 36 36 24211D-16-12 1-7/16"X12 20 12 46.5 14 41 41 24211D-16-16 1-7/16"X12 25 16 48.2 14 41 41 24211D-20-16 1-11/16"X12 25 16 52.7 15 50 50 24211D-20-20 1-11/16"X12 32 20 53.5 15 50 50
PEHEL | ORFS Female Flat Seat Hydraulic Hose Adapter | Double Hexagon Type
PEHEL Hydraulic Model: P24211D
QTY:
Hydraulic Female ORFS Thread Hose Connector Hose Fitting
Material: Carbon steel, Stainless Steel, Aluminium, Brass
Brand: Pehel, OEM
Color: Silver
Connector Type: Straight
Thread Type: Hydraulic Hose Fitting
1. ZINC PLATED CARBON STEEL hydraulic inserts, reliable rust protection & long service life
2. HIGH STRENGTH CARBON STEEL core, withstands high pressure & repeated vibration PRECISION MACHINED shape, tight hose crimping & secure hose assembly
3. STANDARD SIZE hydraulic hose inserts, perfect match for corresponding hydraulic hoses
4. EASY CRIMP INSTALLATION, firm hose connection & reduce risk of blowouts
