PART NO. STECKO SIZE DIMENSIONS LEFT MIDDLE RIGHT A,C B J K M1,M2 N1,N3 S1 EY-04 1/4" 1/4" 1/4" 38 40.5 14.9 9.9 15.16 10.03 16 EY-06 3/8" 3/8" 3/8" 42.5 44 19.9 13.9 20.17 14.02 22 EY-08 1/2" 1/2" 1/2" 46 46.5 23.9 17.9 24.16 18.03 27 EY-12 3/4" 3/4" 3/4" 51.5 52 28.9 23.9 29.16 24.03 36 EY-16 1" 1" 1" 63.5 64 38.8 30.9 39.12 31.01 48 EY-20 1.1/4" 1.1/4" 1.1/4" 63.5 64 45.9 37.9 46.15 38.02 48
Stecko Female / stecko Male
PEHEL Hydraulic Model: EY
QTY:
SAE Stecko Female / Male Adapter and Stecko Fittings
SAE Stecko Male Adapter Fittings
Staple-lock Fittings Stecko Adapters
