PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH A C H S2 20241-14-04T M14X1.5 6 04 40.5 8 18.5 17 20241-16-05T M16X1.5 8 05 44 8 20 19 20241-18-06T M18X1.5 10 06 45 8.5 21 22 20241-22-08T M22X1.5 12 08 58.5 10 24 27 20241-27-10T M27X1.5 16 10 68.6 10.5 24.3 32 20241-36-14T M36X2 22 14 77.3 13 27 41 20241-29-16T M39X2 25 16 83.9 13 29.7 46 20241-45-20T M45X2 32 20 101.5 15 34 55 20241-52-24T M52X2 40 24 108.5 17 38 60 20241-64-32T M64X2 50 32 127.8 23 45.6 75 NOTE:1.For use with braided hoses. 2.If use with spiral hoses,hose fitting series number is 20242-XX-XX。
45° metric Female Flat Seat
PEHEL Hydraulic Model: P20241-T
QTY:
