27891: 90 degree SAE standard fitting
PART NO. tdREAD E HOSE BORE DIMENSIONS DN DASH A C H S2 P27891-04-03 7/16"X20 5 03 26.5 9 30.5 15 P27891-06-04 5/8"X18 6 04 30 11.3 36 22 P27891-06-05 5/8"X18 8 05 33 11.3 39 22 P27891-06-06 5/8"X18 10 06 35.3 11.3 41.3 22 P27891-10-08 7/8"X14 12 08 41 13 47 27 P27891-10-10 7/8"X14 16 10 56.5 13 51.5 27 P27891-12-12 1.1/16"X14 20 12 65.5 14.3 65.3 32 Note: 1.For ues with braided hoses. 2.If use with spiral hoses,hose fitting series number is 27892-XX-XX.
Pehel/27891/90deg Elbow Female SAE 90Deg Cone Hydraulic Hose Fitting
PEHEL Hydraulic Model: P27891
QTY:
27891 90 Degree SAE Female 90 Cone Seat Hydraulic Hose Fitting
- 27891: 90 degree SAE standard fitting.
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver Zinc plating
Connector Type: Elbow
Thread Type: SAE 90deg cone
About the item:
1.Zinc-plated carbon steel body with salt spray resistance up to 240 hours, effectively preventing corrosion in outdoor and humid working environments.
2.Full size range from 1/4" to 1-1/4" to match various hydraulic pipelines
3.Chamfered tube entry guides tubing for error-free assembly, reducing installation misalignment that leads to premature seal wear.
4.Wide operating temperature range from -40℃ to +120℃, stable performance in extreme cold northern mines and high-temperature metallurgy workshops.
