HOSE CONSTRUCTION:
Tube: oil resistant synthetic rubber
Reinforcement: four/six high tensile steel wire spiral layers
Cover: abrasion, ozone and weather resistant synthetic rubber
Temperature range (medium): -40°C to +121°C
Nominal (mm) Nominal (inch) Inside (mm) Wire (mm) Spiral layers Outside (mm) Working pressure (bar) Working pressure (psi) Test pressure (bar) Burst pressure (bar) Bend radius (mm) Weight (kg/m) 19 3/4 19.0 29.2 4 32.0 350 5075 700 1400 240 1.65 25 1 25.4 35.9 4 39.2 350 5075 700 1400 300 2.25 31 1-1/4 31.8 46.8 6 49.8 350 5075 700 1400 420 3.60 38 1-1/2 38.1 54.0 6 57.3 350 5075 700 1400 500 4.75 51 2 50.8 68.4 6 71.9 350 5075 700 1400 630 6.90
heavy duty Wire Spiral Hose-SAE 100 R13-EN 856 R13
PEHEL Hydraulic Model: SAE 100 R13-EN 856 R13
QTY:
About the item:
Material:Rubber
Maximum pressure:5,000 psi / 35 MPa
Outside Diameter: 13mm-51mm
Manufacturer: Pehel
Brand: Pehel/OEM
- 1.Complies with SAE 100 R13 & EN 856 R13 standards, adopts 4/6 layers high-tensile steel wire spiral structure for excellent high pressure resistance up to 350bar.
- 2.Premium oil-resistant inner rubber tube of SAE 100 R13 EN 856 R13 hose ensures stable delivery of various hydraulic fluids.
- 3.Outer cover features outstanding abrasion, ozone and weather resistance, extending service life in harsh working conditions.
- 4.Wide temperature range from -40°C to +121°C, the EN 856 R13 hydraulic hose works reliably in extreme cold and hot environments.
- 5.Excellent flexibility and anti-pulse performance, ideal for heavy-duty construction machinery and mining hydraulic systems.
- 6.High burst pressure and stable performance, the SAE 100 R13 spiral hose reduces leakage risk for long-term operation.
