PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH A C H S2 P24293-12-12W 1.3/16"X12 20 12 73.8 15 80.5 36 P24293-16-16W 1.7/16"X12 25 16 88.9 15 88.5 41 P24293-20-20W 1.11/16"X12 32 20 105.8 15 100 50 P24293-24-24W 2"X12 40 24 123.2 14.8 114.5 60
90º ORFS Female Flat Seat
PEHEL Hydraulic Model: P24293
QTY:
ORFS Flat Seat 90 Degree Fitting
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type:
Thread Type:ORFS Female Thread with Flat Seat
- About the item:
- 1.This 90° ORFS female flat seat elbow adopts ORFS flat seat sealing design to achieve zero leakage under high hydraulic pressure.
- 2.Made of carbon steel and stainless steel, the ORFS flat seat hydraulic elbow fitting has outstanding pressure resistance for heavy-duty equipment.
- 3.Silver zinc plating on this right angle ORFS connector provides excellent rust and corrosion resistance, greatly extending service life.
- 4.We supply Pehel brand products and full OEM customization service for the 90 degree ORFS female flat seat adapter to meet bulk orders.
- 5.Precision machined ORFS female thread of the hydraulic elbow ensures perfect matching with standard ORFS pipeline ports for easy installation.
