PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH A B H S2 21641-04-04 1/4"X18 6 04 42.5 5 20 19 21641-06-06 3/8"X18 10 06 47 6.5 22.5 22 21641-08-08 1/2"X14 12 08 61 7.8 26 27 21641-12-12 3/4"X14 20 12 79.5 10.5 32 32 21641-16-16 1"X11.5 25 16 88.7 11 34 41 21641-20-20 1.1/4"X11.5 32 20 100.5 11.5 40 50 21641-24-24 1.1/2"X11.5 40 24 116 12.5 45 55 21641-32-32 2"X11.5 50 32 144 16 54 70 NOTE:1.For use with braided hoses. 2.If use with spiral hoses,hose fitting series number is 21642-XX-XX。
45° NPSM Female 60° Cone
PEHEL Hydraulic Model: P21641
QTY:
