PART NO.
THREAD TUBE O.D. DIMENSIONS E F D A B L S P1CO-14-04 M14X1.5 7/16"X20 8 13 9.14 28 15 P1CO-16-04 M16X1.5 7/16"X20 10 13.5 9.14 29 17 P1CO-18-06 M18X1.5 9/16"X18 12 13.5 9.93 30 19 P1CO-18-08 M18X1.5 3/4"X16 12 13.5 11.1 33 22 P1CO-18-10 M18X1.5 7/8"X14 12 13.5 12.7 36 27 P1CO-22-08 M22X1.5 3/4"X16 15 13.5 11.1 33 24 P1CO-22-10 M22X1.5 7/8"X14 15 13.5 12.7 36 27 P1CO-26-08 M26X1.5 3/4"X16 18 14 11.1 35 27 P1CO-26-10 M26X1.5 7/8"X14 18 14 12.7 37 27 P1CO-30-10 M30X2 7/8"X14 22 18 12.7 42 32 P1CO-30-12 M30X2 1.1/16"X12 22 18 15.1 44 32 P1CO-36-12 M36X2 1.1/16"X12 28 18 15.1 44 38 P1CO-36-16 M36X2 1.5/16"X12 28 18 15.1 44 38 P1CO-42-16 M42X2 1.5/16"X12 32 19 15.1 47 46 P1CO-52-20 M52X2 1.5/8"X12 42 19 15.1 49 55
Pehel | P1CO | Hydraulic UN UNF Thread Stud Ends with O-ring Sealing ISO 11926
PEHEL Hydraulic Model: P1CO
QTY:
Material: Carbon steel
Brand: Pehel
Color: Silver
OEM Designed: Yes
Surface Treatment: Zinc Plated
Thread: Metric/SAE
About the item:
1. Compact hose fitting – designed for tight spaces with reliable sealing performance.
2. Versatile hose adapter – bridges metric and non-metric systems effortlessly.
3. Precision metric adapter – meets DIN/ISO thread standards for secure connections.
4. Durable construction – carbon steel with anti-corrosion coating for longevity.
5. Easy installation – thread-on design reduces assembly time and maintenance.
