Pehel | P1CFL9-1DFL9-1DFS9-W | 90 Elbow Sae Flange with Standard Series and 90 Elbow SAE Flange with High Pressure Series Hose Adapters

PEHEL Hydraulic Model: 1CFL9-1DFL9-1DFS9-W

QTY:

Material: Carbon steel
Brand: Pehel
Color: Silver
OEM Designed: Yes
Surface Treatment: Zinc Plated
Thread: Metric/Flange
About the item:

1. Versatile fittings – connect metric adapters to flange systems seamlessly.
2. Precision metric adapter – meets DIN/ISO standards for exact thread fit.
3. Flange connection design – ensures secure, leak-free sealing.
4. Durable steel body – corrosion-resistant for high-pressure durability.
5. Easy installation – bolt-on flange saves assembly time.

PART NO.	THREAD E	FLANGE SIZE	TUBE O.D.	DIMENSIONS									MPa
PART NO.	THREAD E	FLANGE SIZE	D1	A	d	h	H	l1	L1	M	N	S2	MPa
1CFL9-22-08W	M22X1.5	1/2"	15	53.8	9	16	18	28	43	38.1	17.5	27	31.5 L
1CFL9-30-12W	M30X2	3/4"	22	65	11	18	22	30.5	47	47.6	22.2	36	16 L L
1CFL9-36-16W	M36X2	1"	28	69.9	11	19	26	34.5	51	52.4	26.2	41
1CFL9-45-20W	M45X2	1.1/4"	35	79.2	11	22	32	37.5	59	58.7	30.2	50
1CFL9-52-24W	M52X2	1.1/2"	42	93.7	13.5	26	36	43	66	69.9	35.7	60
1DFL9-24-08W	M24X1.5	1/2"	16	53.8	9	16	20	28.5	47	38.1	17.5	30	35 S
1DFL9-30-12W	M30X2	3/4"	20	65	11	18	24	29.5	51	47.6	22.2	36
1DFL9-36-16W	M36X2	1"	25	69.9	11	19	30	34	58	52.4	26.2	46
1DFL9-42-20W	M42X2	1.1/4"	30	79.2	11	22	32	38.5	65	58.7	30.2	50	28 S
1DFL9-52-24W	M52X2	1.1/2"	38	93.7	13.5	26	36	44	75	69.9	35.7	60	21 S
Note:In case if you are interested to order the adapter in complete set with cutting ring and nut ,it is necessary to insert suffix "RN" after our part no.,for example 1DFL9-52-24W/RN.
PART NO.	THREAD E	FLANGE SIZE	TUBE O.D.	DIMENSIONS									MPa
PART NO.	THREAD E	FLANGE SIZE	D1	A	d	h	H	l1	L1	M	N	S2	MPa
1DFS9-24-08W	M24X1.5	1/2"	16	56.3	9	16	20	28.5	47	40.5	18.2	30	40S
1DFS9-30-12W	M30X2	3/4"	20	71.4	11	19	26	30.5	52	50.8	23.8	36
1DFS9-36-16W	M36X2	1"	25	81	13	24	32	36	60	57.2	27.8	46
1DFS9-42-20W	M42X2	1.1/4"	30	95.3	15	25	38	41.5	68	66.7	31.8	50
1DFS9-52-24W	M52X2	1.1/2"	38	112.8	17	26	40	45	76	79.4	36.6	60	31.5 S
Note:In case if you are interested to order the adapter in complete set with cutting ring and nut ,it is necessary to insert suffix "RN" after our part no.,for example 1DFS9-52-24W/RN.
