THREAD DIMENSIONS PART NO. E A L S2 9J-04 7/16"X20 9.5 10.5 17 9J-05 1/2"X20 9 11 19 9J-06 9/16"X18 9.5 12 19 9J-08 3/4"×16 10.8 13 24 9J-10 7/8"X14 12 14.5 27 9J-12 1.1/16"X12 13 15.5 32 9J-14 1.3/16"×12 15 16 36 9J-16 1.5/16"X12 14 17 41 9J-20 1.5/8"×12 15 19 50 9J-24 1.7/8"X12 19 19.5 55 9J-32 2.1/2"×12 23.5 21.5 75
JIC Female 74° Seat Plug Cap Carbon Steel Hydraulic Pipe Fitting
PEHEL Hydraulic Model: P9J
QTY:
Material:Carbon steel
Brand:Pehel, OEM
Color: Silver
Connector Type: Cap
Thread Type: JIC
Surface Treatment: CR3+ White Zinc Plated
About the item:
- 1. Dual Material OptionsChoose from carbon steel or stainless steel for your JIC female plug cap, ensuring excellent strength and corrosion resistance in harsh hydraulic environments.
- 2.Protective Zinc PlatingFinished with silver color zinc plating, these 74° seat caps offer superior rust protection, extending the service life of your hydraulic components.
- 3. Precision 74° Seat SealEngineered with a standard 74° seat, our JIC female plug guarantees a tight, leak-free seal when closing off hydraulic lines or adapters.
- 4. Versatile Hydraulic UseDesigned as a reliable hydraulic fitting cap, it safeguards threaded connections against dirt and damage during storage, transit, or system maintenance.
- 5.Easy Installation & RemovalThis JIC female 74° seat plug cap features accurate threading for quick hand tightening or tool operation, saving time in assembly and disassembly.
