PART NO. THREAD O-RING DIMENSIONS E E A L S1 4F-04 9/16"X18 7.65X1.78 9.8 16.8 17 4F-06 11/16"X16 9.25X1.78 11.2 19.2 19 4F-08 13/16"X16 12.42X1.78 12.8 21.8 22 4F-10 1"X14 15.6X1.78 15.5 25.9 27 4F-12 1.3/16"X12 18.77X1.78 17 27.4 32 4F-16 1.7/16"X12 23.52X1.78 17.5 27.9 38 4F-20 1.11/16"X12 29.87X1.78 17.5 27.9 46 4F-24 2"X12 37.82X1.78 17.5 27.9 55
PEHEL/ORFS MALE PLUG
PEHEL Hydraulic Model: 4F
QTY:
ORFS MALE PLUG
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: PLUG
Thread Type: ORFS MALE
About the item:
1. Hex head plug with ORFS flat-face male thread, model 4F.
2. O-ring under the head provides a reliable, leak-tight flat-face seal without thread sealant.
3. Available from 9/16"-18 to 2"-12 for a wide range of port sizes.
4. Precision-machined carbon steel construction delivers high strength and long service life.
5. Ideal for sealing hydraulic, pneumatic, oil and gas flat-face ports and manifolds.
