PART NO. THREAD TUBE O.D. DIMENSIONS E F D A B S1 S2 1QT9-14-04SP M14X1.5 R1/4"X19 8 30.2 25.5 14 17 1QT9-14-04SP M14X1.5 R1/4"X19 8 30.2 25.5 14 17 1QT9-16-04SP M16X1.5 R1/4"X19 10 32 26.5 16 19 1QT9-18-06SP M18X1.5 R3/8"X19 12 34 30.5 19 22 1QT9-18-08SP M18X1.5 R1/2"X14 12 36 36 22 22 1QT9-22-08SP M22X1.5 R1/2"X14 14 37.5 36 22 27 1QT9-27-08SP M27X1.5 R1/2"X14 18 41.5 39.5 27 32 1QT9-30-12SP M30X1.5 R3/4"X14 20 45.8 45.3 30 36 1QT9-33-12SP M33X2 R3/4"X14 22 49.5 47.5 33 41 1QT9-36-16SP M36X2 R1"X11 25 51.5 52 36 41 1QT9-39-16SP M39X2 R1"X11 28 55.5 56.5 41 46 1QT9-45-20SP M45X2 R1.1/4"X11 34 62.5 61 48 50 Note:In case if you are interested to order the adapter in complete set with sleeve and nut ,it is necessary to insert suffix "RN" after our part no.,for example 1QT9-18-08SP/RN
OEM Hydraulic Adapter | 90 Elbow Metric 74 Cone Male X BSPT Male Connector
PEHEL Hydraulic Model: 1QT9-SP
QTY:
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type:
Thread Type:
About the item:
- This 90 degree metric male 74 cone fitting with BSPT male thread delivers tight leak-free connection for high-pressure hydraulic pipelines.
- Made of carbon steel & stainless steel with silver zinc plating, the hydraulic elbow offers strong anti-rust performance for long service life.
- Precision machined metric 74 cone seat and tapered BSPT male thread ensure perfect matching with standard hydraulic tubing systems.
- Pehel & OEM customizable hydraulic adapter supports all common hydraulic equipment, flexible for various industrial installation demands.
- 90° elbow connector design efficiently changes pipeline direction without extra joint accessories, saving assembly space and time.
