PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH A C S1 S2 Per hundred weight Weight per case P26711D-04-04SM 7/16"X20 6 4 20 9 12 15 3.1 300 P26711D-05-04SM 1/2"X20 6 4 20.5 9.5 12 17 300 P26711D-06-04SM 9/16"X18 6 4 21 10.5 14 19 250 P26711D-06-06SM 9/16"X18 10 6 21 10.5 17 19 4.6 200 P26711D-08-06SM 3/4"X16 10 6 23 11 19 24 6.7 170 P26711D-08-08SM 3/4"X16 12 8 24.5 11 22 24 150 P26711D-08-10SM 3/4"X16 16 10 25.5 11 22 24 120 P26711D-10-08SM 7/8"X14 12 8 24 13 22 27 100 P26711D-10-10SM 7/8"X14 16 10 27 13 22 27 100 P26711D-12-12SM 1.1/16"X12 20 12 31.5 15 27 32 100 P26711D-16-12SM 1.5/16"X12 20 12 31.5 16 32 41 80 P26711D-16-16SM 1.5/16"X12 25 16 32.5 16 32 41 60 P26711D-20-20SM 1.7/16"X12 32 20 37 17 41 50 30
PEHEL / 26711D-SM / Hydraulic Fittings JIC Female 74°cone Seat Double Hexagon Long-lasting Rust Protection
PEHEL Hydraulic Model: P26711D-SM
QTY:
American Standard Jic Female Swivel Hydraulic Hose Fitting 26711
Hydraulic Fittings JIC Female 74°cone Seat Double Hexagon Long-lasting Rust Protection Easier To Install
Material: Carbon steel
Surface Treatment: White Zinc Plating
Brand: PEHEL, OEM
Color: Silver
Connector Type: Straight
Thread: JIC
1. PEHE26711D-SM JIC fitting with 37° cone for leak-free hydraulic connections.
2. Carbon steel with zinc plating ensures superior durability and corrosion resistance.
3. Professional design delivers reliable sealing under high pressure and extreme temperatures.
4. Compatible with multiple fluid types, including oil, water, and air.
5. JIC female 37° cone with O-ring seal prevents fluid escape in demanding industrial applications.
