PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH A C H S2 26793-12-12W 1.1/16"X12 20 12 73.5 14.5 63 32 26793-16-16W 1.5/16"X12 25 16 89.3 15.6 71 41 26793-20-20W 1.5/8"X12 32 20 106 16.1 81.5 50 26793-24-24W 1.7/8"X12 40 24 124.3 19.5 101 55 26793-32-32W 2.1/2"X12 50 32 150.5 23.6 121.3 75
Pehel | P26793-W| Hydraulic 90° JIC Female 74° Cone Seat Hose Fittings
PEHEL Hydraulic Model: P26793-W
QTY:
26793-W JIC 90° Elbow Female 74° Cone Fittings
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: Female Fittings/Interlock
Thread Type: JIC
About the item:
1. Secure hose fitting – interlock design prevents accidental disconnection under pressure.
2. Precision JIC fitting – meets SAE J514 standards for reliable flare sealing.
3. Built-in interlock mechanism – ensures positive locking between male and female ends.
4. Thrust wire reinforcement – retains connection integrity under vibration and impulse.
5. Durable tee body – forged steel with corrosion-resistant finish for long service life.
