PART NO. tdREAD E HOSE BORE O-RING DIMENSIONS DN DASH A C S1 Per hundred weight Weight per case P14211-04-04 9/16"X18 6 4 O011 22.3 9.8 17 2.9 300 P14211-06-04 11/16"X16 6 4 O012 24 11.2 19 4.3 200 P14211-06-06 11/16"X16 10 6 O012 24 11.2 19 4.4 200 P14211-08-06 13/16"X16 10 6 O014 27.5 12.8 22 6.6 180 P14211-08-08 13/16"X16 12 8 O014 28.5 12.8 22 7 150 P14211-08-10 13/16"X16 16 10 O014 28.5 12.8 22 8 100 P14211-10-08 1"X14 12 8 O016 32.5 15.5 27 11 120 P14211-10-10 1"X14 16 10 O016 34 15.5 27 10.9 200 P14211-12-08 1.3/16"X12 12 8 O018 35.5 17 32 17 200 P14211-12-10 1.3/16"X12 16 10 O018 36.5 17 32 17.2 200 P14211-12-12 1.3/16"X12 20 12 O018 36.5 17 32 24.2 150 P14211-16-12 1.7/16"X12 20 12 O021 37 17.5 38 27 100 P14211-16-16 1.7/16"X12 25 16 O021 38.5 17.5 38 27.8 80 P14211-20-20 1.11/16"X12 32 20 O025 41.5 17.5 46 42 50 P14211-24-24 2"X12 40 24 O029 43.5 17.5 55 68.3 30
Pehel/14211/ORFS Male O-ring Seal Straight Hydraulic Hose Fitting
PEHEL Hydraulic Model: P14211
QTY:
ORFS Flat O-Ring Seal Hydraulic Hose Fitting 14211
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver Zinc plating
Connector Type: Straight
Thread Type: ORFS
About the item:
1.Full through-bore design maintains consistent internal flow diameter, avoiding flow restriction that causes system heat rise and efficiency loss.
2.Reliable Manufacturing Quality:15+ years of professional hydraulic component production experience, certified quality control system.
3.Wide operating temperature range from -40℃ to +120℃, stable performance in extreme cold northern mines and high-temperature metallurgy workshops.
