PART NO. THREAD DIMENSIONS E F A B S1 5J-04-05 7/16"X20 1/2"X20 30.6 14 17 5J-05-06 1/2"X20 9/16"X18 33.7 14 19 5J-06-04 9/16"X18 7/16"X20 30.6 14.1 17 5J-08-10 3/4"X16 7/8"X14 36.2 16.7 30 5J-10-12 7/8"X14 1.1/16"X12 45.1 19.3 32 5J-12-10 1.1/16"X12 7/8"X14 43 21.9 30 5J-16-12 1.5/16"X12 1.1/16"X12 50 23.1 36 Nut and sleeve should be ordered separately.The nut NB200 and sleeve NB500 is suitable for metric tube,the nut NB200 and sleeve NB300 is suitable for inch tube.
Pehel | P5J| Hydraulic JIC Male 74 Cone/JIC Female 74 Cone Reducer Adapter
PEHEL Hydraulic Model: 5J
QTY:
Material: Carbon steel
Brand: Pehel
Color: Silver
Connector Type: Straight
Thread Type: JIC Female
About the item:
1. Versatile hose adapter – connects JIC systems with different thread sizes.
2. Precision JIC Adapter – meets SAE J514 standards for reliable flare sealing.
3. Built-in reducer – allows step-down or step-up between JIC port and hose.
4. Durable steel construction – zinc-plated for corrosion and fatigue resistance.
5. Quick size conversion – eliminates need for multiple fittings in one connection.
