PART NO. THREAD DIMENSIONS E F A B S1 5JT9-04-02 7/16"x20 Rc1/8"X28 27.5 20 16 5JT9-04 7/16"x20 Rc1/4"X19 30 25 19 5JT9-05-04 1/2"X20 Rc1/4"X19 30 25 19 5JT9-06 9/16"X18 Rc3/8"X19 33.5 27 24 5JT9-06-04 9/16"X18 Rc1/4"X19 30.5 25 19 5JT9-08 3/4"X16 Rc1/2"X14 39.5 31.5 30 5JT9-08-06 3/4"X16 Rc3/8"X19 36 27 24 5JT9-10-08 7/8"X14 Rc1/2"X14 42.5 31.5 30 5JT9-12 1.1/16"X12 Rc3/4"X14 48 37 33 5JT9-12-08 1.1/16"X12 Rc1/2"X14 46.2 31.5 30 5JT9-16 1.5/16"X12 Rc1"X11 54 43 41 5JT9-20 1.5/8"X12 Rc1.1/4"X11 62 46 50 5JT9-24 1.7/8"X12 Rc1.1/2"X11 74.5 55 63 Nut and sleeve should be ordered separately.The nut NB200 and sleeve NB500 is suitable for metric tube,the nut NB200 and sleeve NB300 is suitable for inch tube.
PEHEL | 90° JIC Male 74° Cone to BSPT Female Adapter, Hydraulic Elbow Fitting with Tapered BSPT Female Port
PEHEL Hydraulic Model: 5JT9
QTY:
Type: 90° Elbow Adapter
End 1: JIC Male 74° Cone
End 2: BSPT Female (tapered thread)
Material: Carbon steel
Brand: PEHEL, OEM
Surface Treatment: Zinc‑plated
About the item:
1.90° JIC male 74° cone to BSPT female adapter, designed as an angled fitting for transitioning between JIC male ports and BSPT female threaded components in hydraulic systems.
2.JIC male end features a 74° cone sealing face, providing reliable metal‑to‑metal seal under high pressure against standard JIC female swivel nuts.
3.BSPT female end incorporates tapered (parallel) threads conforming to British Standard Pipe Taper, ensuring tight engagement with BSPT male fittings.
4.90° elbow configuration allows directional change of fluid flow in confined spaces, simplifying hydraulic circuit layout.
5.Manufactured from high‑strength carbon steel with anti‑rust surface treatment for long service life in demanding industrial environments.
