PART NO. THREAD E HOSE BORE DIMENSIONS DN DASH C S1 Per hundred weight Weight per case P12611-02-04 G1/8"-28 6 4 10 12 1.9 400 P12611-04-04 G1/4"-19 6 4 12 14 2.3 300 P12611-04-06 G1/4"-19 10 6 12 17 3.7 300 P12611-06-04 G3/8"-19 6 4 13.5 17 3.5 250 P12611-06-05 G3/8"-19 8 5 13.5 17 3.7 250 P12611-06-06 G3/8"-19 10 6 13.5 17 4.1 250 P12611-06-08 G3/8"-19 12 8 13.5 17 6 150 P12611-08-06 G1/2"-14 10 6 16 22 6.3 125 P12611-08-08 G1/2"-14 12 8 16 22 7 125 P12611-10-08 G5/8"-14 12 8 17.5 24 8.7 100 P12611-10-10 G5/8"-14 16 10 17.5 24 8.7 200 P12611-12-08 G3/4"-14 12 8 18.5 30 12 70 P12611-12-10 G3/4"-14 16 10 18.5 30 12 150 P12611-12-12 G3/4"-14 20 12 18.5 30 14 150 P12611-16-12 G1"-11 20 12 20.5 36 20.5 100 P12611-16-16 G1"-11 25 16 20.5 36 23.9 70 P12611-20-16 G1.1/4"-11 25 16 20.5 46 35.6 50 P12611-20-20 G1.1/4"-11 32 20 20.5 46 39.4 50 P12611-24-24 G1.1/2"-11 40 24 23 50 61.5 30 P12611-32-32 G2"-11 50 32 25.5 65 18
PEHEL/ BSP Male 60º Cone Seat
PEHEL Hydraulic Model: P12611
QTY:
Male Bsp 60o Cone Seat Hydralic Fitting 12611
Fetures:
Trivalent Coated Carbon Steel，BSP (British Standard Pipe) is a common thread outside North America. BSPT (T = Tapered) tapers down while BSPP (P = Parallel) is a straight thread.
BSP Male 60º Cone Seat
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: Hose fittings
Thread Type: BSP Male 60 Cone
About th eitem:
1. P12611 is crimp‑style hydraulic hose fitting with BSP male 60° cone seat for high‑pressure hose assembly.
2. 60‑degree metal‑to‑metal cone sealing delivers stable leak‑proof performance for BSP standard hydraulic circuits.
3. Broad size range covers G1/8"‑G2" BSP threads, matching hose bore DN6‑DN50 for diverse crimping requirements.
4. Precisely CNC‑machined carbon‑steel body with trivalent zinc‑plated finish, ensuring good interchangeability and corrosion resistance.
5. Standard BSP hose end widely used for industrial, agricultural and mobile heavy‑duty hydraulic equipment.
