PART NO.
THREAD DIMENSIONS E F A B S1 S2 L P3B-04 G1/4"-19 G1/4"-19 4 4 19 19 28 -06 G3/8"-19 G3/8"-19 5 5 22 22 31 -08 G1/2"-14 G1/2"-14 6 6 27 27 35 -12 G3/4"-14 G3/4"-14 9 9 32 32 38 -16 G 1"-11 G 1"-11 10.5 10.5 41 41 40
Pehel | BSP Female 60 Degree Cone Hydraulic Transition Fitting
PEHEL Hydraulic Model: 1-P3B
QTY:
- Brand: Pehel, OEM Available
- Material: Carbon Steel, Stainless Steel
- Surface Treatment: Silver Zinc Plating, Chrome Plating, Nickel Plating
- Type: Hydraulic Transit Joint
- Connector Type: BSP Female, 60° Cone
- Thread Type: BSP Female Thread
- Application: Hydraulic pipeline transition connection
- Feature: Leak-proof cone seal, precision machining
About the item:
- 1.This BSP female 60 degree cone fitting adopts cone face sealing to block hydraulic medium leakage.
- 2.Standard BSP female thread of this hydraulic transition fitting ensures seamless connection with BSP pipe components.
- 3.The 60° cone seal hydraulic connector maintains stable sealing performance under high working pressure.
- 4.Made in carbon steel or stainless steel, this BSP thread hydraulic adapter fits diverse harsh hydraulic environments.
- 5.Multiple surface treatments: zinc plating, chrome plating, nickel plating improve anti-rust capability.
- 6.Pehel provides ready stock hydraulic pipe joints and accepts OEM custom hydraulic connector specifications.
