JIC MALE 74 CONE

PEHEL Hydraulic Model: 1J-H

QTY:

Send Inquiry

JIC MALE 74 CONE Specification
You May Also Like

PART NO.	THREAD		DIMENSIONS
PART NO.	E	F	A	B	L	S1
1J-04H	7/16"X20	7/16"X20	14	14	34	17
1J-05H	1/2"X20	1/2"X20	14	14	34	19
1J-06H	9/16"X18	9/16"X18	14.1	14.1	34.2	22
1J-08H	3/4"X16	3/4"X16	16.7	16.7	42	27
1J-10H	7/8"X14	7/8"X14	19.3	19.3	46.5	30
1J-12H	1.1/16"X12	1.1/16"X12	21.9	21.9	54	36
1J-14H	1.3/16"X12	1.3/16"X12	22.6	22.6	56	38
1J-16H	1.5/16"X12	1.5/16"X12	23.1	23.1	57	41
1J-20H	1.5/8"X12	1.5/8"X12	24.3	24.3	62	50
1J-24H	1.7/8"X12	1.7/8"X12	27.5	27.5	70	55
