Home / Hydraulic Adapter Japanese Adapter / Japanese Metric Thread 60° Cone Fitting / Metric Male 60 Seat Bulkhead
Metric Male 60 Seat Bulkhead

Metric Male 60 Seat Bulkhead

PEHEL Hydraulic Model: 6M

QTY:

  • Metric Male 60 Seat Bulkhead Specification
  • You May Also Like
  • PART NO. THREAD DIMENSIONS
    E F A B L S1
    6M-12 M12X1.5 M12X1.5 15 34 53 17
    6M-14 M14X1.5 M14X1.5 15 34 53 19
    6M-16 M16X1.5 M16X1.5 14 36 57 22
    6M-18 M18X1.5 M18X1.5 16 36 59 24
    6M-20 M20X1.5 M20X1.5 16 36 62 27
    6M-22 M22X1.5 M22X1.5 17 38 65 30
    6M-24 M24X1.5 M24X1.5 17 59 67 32
    Note :In case if you are interested to order the adapter in complete set with lock nut ,it is necessary to insert suffix "LN" after our part no.,for example 6M-16LN
