PART NO. THREAD DIMENSIONS E F A L S1 5BN-02 G1/8"X28 Z1/8"X27 10 25 17 5BN-04 G1/4"X19 Z1/4"X18 12 31 19 5BN-04-02 G1/4"X19 Z1/8"X27 12 27 19 5BN-04-06 G1/4"X19 Z3/8"X18 12 33 22 5BN-06 G3/8"X19 Z3/8"X18 13.5 33 22 5BN-06-04 G3/8"X19 Z1/4"X18 13.5 32 22 5BN-08 G1/2"X14 Z1/2"X14 16 44 30 5BN-08-04 G1/2"X14 Z1/4"X18 16 23 27 5BN-08-06 G1/2"X14 Z3/8"X18 16 34 27 5BN-08-12 G1/2"X14 Z3/4"X14 16 43 36 5BN-12 G3/4"X14 Z3/4"X14 18.5 45 36 5BN-12-04 G3/4"X14 Z1/4"X18 18.5 26.5 32 5BN-12-06 G3/4"X14 Z3/8"X18 18.5 26.5 32 5BN-16 G1"X11 Z1"X11.5 20.5 54 41 5BN-16-04 G1"X11 Z1/4"X18 20.5 32 41 5BN-16-06 G1"X11 Z3/8"X18 20.5 32 41 5BN-16-08 G1"X11 Z1/2"X14 20.5 32 41 5BN-16-12 G1"X11 Z3/4"X14 20.5 44 41 5BN-16-20 G1"X11 Z1.1/4"X11.5 20.5 58 50 5BN-20 G1.1/4"X11 Z1.1/4"X11.5 20.5 58 50 5BN-20-16 G1.1/4"X11 Z1"X11.5 20.5 48 50 5BN-24 G1.1/2"X11 Z1.1/2"X11.5 23 58 60 5BN-24-16 G1.1/2"X11 Z1"X11.5 23 43 55 5BN-24-20 G1.1/2"X11 Z1.1/4"X11.5 23 56 55 5BN-32 G2"X11 Z2"X11.5 25.5 62 70
BSP MALE 60 SEAT/NPT FEMALE
PEHEL Hydraulic Model: 5BN
QTY:
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type: Thread conversion hydraulic straight adapter
Thread Type: BSP male thread with 60 degree seat, NPT female tapered thread
About the item:
- 1.This BSP male 60 seat NPT female adapter realizes seamless conversion between BSP and NPT standard hydraulic pipelines.
- 2.Precision machined 60 seat on BSP male end provides tight metal-to-metal sealing to avoid leakage under high hydraulic pressure.
- 3.Made of carbon steel & stainless steel with silver zinc plating, the BSP NPT thread conversion fitting features excellent anti-rust performance.
- 4.Standard NPT female tapered thread perfectly matches American hydraulic equipment ports, widely applicable for global machinery systems.
- 5.Pehel supports OEM customization for this hydraulic straight adapter, supplying multiple sizes of BSP male 60 seat NPT female couplers.
