PART NO. THREAD DIMENSIONS E F G A B C S1 S2 S3 FB-04 G1/4"X19 G1/4"X19 G1/4"X19 5.5 5.5 24.5 14 19 19 FB-06 G3/8"X19 G3/8"X19 G3/8"X19 6.3 6.3 27.5 16 22 22 FB-08 G1/2"X14 G1/2"X14 G1/2"X14 7.5 7.5 34.5 22 27 27 FB-10 G5/8"X14 G5/8"X14 G5/8"X14 9.5 9.5 35 22 30 30 FB-12 G3/4"X14 G3/4"X14 G3/4"X14 10.9 10.9 40 27 32 32 FB-12-08-12 G3/4"X14 G1/2"X14 G3/4"X14 10.9 7.5 40 27 32 27 FB-16 G1"X11 G1"X11 G1"X11 11.7 11.7 46 33 41 41 FB-20 G1.1/4"X11 G1.1/4"X11 G1.1/4"X11 11 11 50.5 41 50 50 FB-24 G1.1/2"X11 G1.1/2"X11 G1.1/2"X11 13 13 57.5 48 55 55
PEHEL | BSP Female x Female x Male Threaded Tee, 3‑Way Hydraulic Fitting for Pipe Branching
PEHEL Hydraulic Model: FB
QTY:
Type: Tee / T‑Fitting
Port 1: BSP Female
Port 2: BSP Female
Port 3: BSP Male
Material: Carbon steel
Brand: PEHEL, OEM
Surface Treatment: Zinc‑plated or anti‑rust coated
About the item:
1.BSP female to female to male tee, designed as a three‑way fitting for splitting or combining fluid flow in hydraulic and pneumatic systems.
2.Two ends feature BSP female threads, accepting BSP male connectors; the remaining end features a BSP male thread for connection to BSP female ports.
3.The T‑shaped body provides a compact branching solution, allowing easy integration into existing piping layouts.
4.Manufactured from high‑strength carbon steel with anti‑rust surface treatment for reliable performance in demanding environments.
5.Precision machined threads ensure consistent fit and leak‑free operation with standard BSP fittings.
