PART NO. THREAD DIMENSIONS E F A B L S1 1JT-04-02SP 716"X20 R1/8"X28 14 10 30 12 1JT-04SP 7/16"X20 R1/4"X19 14 14.5 34.5 14 1JT-04-06SP 7/16"X20 R3/8"X19 14 15 35 17 1JT-05-02SP 1/2"x20 R1/8"X28 14 10.5 30.5 14 1JT-05-04SP 1/2"x20 R1/4"X19 14 14.5 34 14 1JT-05-06SP 1/2x20 R3/8""X19 14 15 35 17 1JT-06-02SP 9/16"X18 R1/8"X28 14.1 10.5 30.5 17 1JT-06-04SP 9/16×18 R1/4"X19 14.1 14.5 34 17 1JT-06SP 9/16"×18 R3/8"X19 14.1 15 34 17 1JT-06-08SP 9/16"×18 R1/2""X14 14.1 20 41 22 1JT-08-06SP 3/4x16 R3/8"X19 16.7 15 39 22 1JT-08SP 3/4"X16 R1/2""X14 16.7 20 44.5 22 1JT-08-12SP 3/4"X16 R3/4"X14 16.7 20 46 30 1JT-10-06SP 7/8""X14 R3/8"X19 16.7 15 42.5 24 1JT-10-08SP 7/8"X14 R1/2"X14 19.3 20 46.5 24 1JT-10-12SP 7/8""X14 R3/4""X14 19.3 20 48.5 30 1JT-12-08SP 1.1/16"X12 R1/2"X14 21.9 20 51 30 1JT-12SP 1.1/16"X12 R34"X14 21.9 20 51 30 1JT-12-16SP 1.1/16“X12 R1"X11 21.9 25.5 57.5 36 1JT-14-12SP 1.3/16"X12 R3/4"14 22.6 20 52.5 32 1JT-14-16SP 1.3/16"X12 R1"X11 22.6 25.5 57.5 36 1JT-16-12SP 1.5/16"X12 R3/4""X14 23.1 20 53 36 1JT-16SP 1.5/16"X12 R1"X11 23.1 25.5 59 36 1JT-16-20SP 1.5/16"X12 R1.1/4""X11 23.1 26.5 61.5 46 1JT-20-16SP 1.5/8"X12 R1"X11 24.3 25.5 62.5 46 1JT-20SP 1.5/8"X12 R1.1/4""X11 24.3 26.5 63 46 1JT-20-24SP 1.5/8""X12 R1.1/2"X14 24.3 26.5 66.5 50 1JT-24-20SP 1.7V8""X12 R1.1/4"X11 27.5 26.5 67.5 50 1JT-24SP 1.7V8""X12 R1.1/2"X11 27.5 26.5 59.5 50 1JT-24-32SP 1,7/8"X12 R2""X11 27.5 30 73.6 65 1JT-32-24SP 2.1/2"“X12 R1.1/2"×11 33.9 26.5 77.5 65 1JT-32SP 2.1/2"×12 R2"X11 33.9 30 80 65
Pehel | JIC Male 74° Cone / BSPT Male Adapter (SAE J514)
PEHEL Hydraulic Model: P1JT-SP
QTY:
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type:
Thread Type:
About the item:
- 1.Dual-standard bridge – This JIC / BSPT adapter joins JIC 74° cone UNF ends and British tapered pipe threads in one compact male fitting.
- 2.Precision 74° cone seal – The JIC male 74° cone end (SAE J514) delivers reliable metal-to-metal sealing for high-pressure JIC systems.
- 3.Tapered BSPT threads – The BSPT male fitting end uses 1:16 tapered threads (ISO 7 / BS 21) for a snug, leak-tight fit with BSPT ports.
- 4.Corrosion-resistant build – Carbon steel or stainless steel with silver zinc plating keeps this JIC 74° cone / BSPT adapter durable in harsh environments.
- 5.Space-saving male design – A compact straight hydraulic adapter simplifies plumbing between JIC and BSPT components without extra elbows.
