90 METRIC O-RING MALE/BSPP FEMALE 60 CONE

Model: 2HB9-OG

QTY:

  • You May Also Like

  • PART NO. THREAD O-RING DIMENSIONS
    E F E A B S1 S2 S3
    2HB9-10-02OG M10X1 G1/8"X28 8.1X1.6 26.5 5.5 11 14 14
    2HB9-12-02OG M12X1.5 G1/8"X28 9.3X2.4 32 5.5 14 14 17
    2HB9-12-04OG M12X1.5 G1/4"X19 9.3X2.4 32 5.5 14 19 17
    2HB9-14-04OG M14X1.5 G1/4"X19 11.3X2.4 32 5.5 14 19 19
    2HB9-14-06OG M14X1.5 G3/8"X19 11.3X2.4 32 6.3 14 22 19
    2HB9-16-04OG M16X1.5 G1/4"X19 13.3X2.4 34.8 5.5 16 19 22
    2HB9-16-06OG M16X1.5 G3/8"X19 13.3X2.4 34.8 6.3 16 22 22
    2HB9-18-06OG M18X1.5 G3/8"X19 15.3X2.4 37 6.3 19 22 24
    2HB9-18-08OG M18X1.5 G1/2"X14 15.3X2.4 37 7.5 19 27 24
    2HB9-20-08OG M20X1.5 G1/2"X14 17.3X2.4 40 7.5 22 27 27
    2HB9-22-08OG M22X1.5 G1/2"X14 19.3X2.4 40.2 7.5 22 27 27
    2HB9-22-10OG M22X1.5 G5/8"X14 19.3X2.4 40.2 9.5 22 30 27
    2HB9-22-12OG M22X1.5 G3/4"X14 19.3X2.4 41.2 10.9 24 32 27
    2HB9-27-12OG M27X2 G3/4"X14 23.5X3 48.5 10.9 27 32 32
    2HB9-27-16OG M27X2 G1"X11 23.5X3 50 11.7 30 41 32
    2HB9-33-16OG M33X2 G1"X11 29.2X3 52.5 11.7 33 41 41
    2HB9-42-20OG M42X2 G1.1/4"X11 38.5X3 57.2 11 41 50 50
    2HB9-48-24OG M48X2 G1.1/2"X11 44.5X3 62.7 13 48 55 55
