PEHEL | JIC Male Hydraulic Hose Fitting SAE 37° Cone Seat 16711

PEHEL | JIC Male Hydraulic Hose Fitting SAE 37° Cone Seat 16711

PEHEL Hydraulic Model: P16711

QTY:

Male Jic Hydraulic 74D Cone Hose Fitting 16711

  • Material:Carbon Steel

    Brand:Pehel, OEM

    Color: Silver

    Connector Type: Male Steel Fitting

    Thread Type: JIC

    Surface Treatment: Cr3+ White Zinc Plated

  • About the item:

  • · 1.Forged Construction: Ensures durability and strength for heavy-duty applications.

  • · 2.High Pressure Rating: Designed to withstand high-pressure hydraulic systems.

  • · 3. Zinc Plated Finish: Provides rust resistance and enhances longevity.

  • · 4. Strict tolerance crimp stem enables stable hose crimping, avoids hose pull-off & oil seepage.

  • · 5. Customizable Options: Available in various sizes and configurations for tailored solutions.

  • Specification
  • Features
  • You May Also Like
  • PART NO.
    THREAD E
    HOSE BORE DN
    HOSE BORE DASH
    DIMENSIONS C
    DIMENSIONS S2
    Per hundred weight
    Weight per case
    P16711-04-04
    7/16"x20
    6
    4
    14
    12
    1.9
    350
    P16711-05-04
    1/2"x20
    6
    4
    14
    14
    2.5
    300
    P16711-05-05
    1/2"x20
    8
    5
    14
    14
    2.4
    300
    P16711-06-04
    9/16"x18
    6
    4
    14
    17
    3.3
    200
    P16711-06-05
    9/16"x18
    8
    5
    14
    17
    3.2
    200
    P16711-06-06
    9/16"x18
    10
    6
    14
    17
    3.3
    200
    P16711-08-06
    3/4"x16
    10
    6
    16.7
    22
    6.5
    180
    P16711-08-08
    3/4"x16
    12
    8
    16.7
    22
    6.7
    150
    P16711-10-06
    7/8"x14
    10
    6
    19.3
    24
    8.6
    150
    P16711-10-08
    7/8"x14
    12
    8
    19.3
    24
    8.7
    120
    P16711-10-10
    7/8"x14
    16
    10
    19.3
    24
    8
    200
    P16711-12-08
    1.1/16"x12
    12
    8
    22
    30
    11
    100
    P16711-12-10
    1.1/16"x12
    16
    10
    22
    30
    13
    200
    P16711-12-12
    1.1/16"x12
    20
    12
    22
    30
    15
    150
    P16711-12-16
    1.1/16"x12
    25
    16
    22
    32
    24.4
    100
    P16711-14-10
    1.3/16"x12
    16
    10
    22.5
    32
    100
    P16711-14-12
    1.3/16"x12
    20
    12
    22.5
    32
    19.1
    100
    P16711-16-12
    1.5/16"x12
    20
    12
    23
    36
    24
    100
    P16711-16-16
    1.5/16"x12
    25
    16
    23
    36
    25
    80
    P16711-20-16
    1.5/8"x12
    25
    16
    24.3
    46
    42
    50
    P16711-20-20
    1.5/8"x12
    32
    20
    24.3
    46
    41
    50
    P16711-24-20
    1.7/8"x12
    32
    20
    27.5
    50
    58.7
    30
    P16711-24-24
    1.7/8"x12
    40
    24
    27.5
    50
    65
    30
    P16711-32-32
    2.1/2"x12
    50
    32
    34
    65
    18
