PART NO. THREAD DIMENSIONS E F A B S1 7B4-02 G1/8"X28 G1/8"X28 18.5 18.5 16 7B4-04 G1/4"X19 G1/4"X19 20 20 19 7B4-06 G3/8"X19 G3/8"X19 25 25 24 7B4-08 G1/2"X14 G1/2"X14 27.5 27.5 27 7B4-12 G3/4"X14 G3/4"X14 31.5 31.5 33 7B4-16 G1"X11 G1"X11 37.5 37.5 41 7B4-20 G1.1/4"X11 G1.1/4"X11 48 48 50 7B4-24 G1.1/2"X11 G1.1/2"X11 53 53 60 7B4-32 G2"X11 G2"X11 62 62 70
PEHEL/45 ELBOW BSP FEMALE ADAPTER
PEHEL Hydraulic Model: 7B4
QTY:
45 ELBOW BSP FEMALE ADAPTER
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: elbow
Thread Type: BSPP 60 CONE FEMALE
ABOUT THE ITEM:
1. 45 BSP Female — 45-degree BSP female elbow with 60° cone seat for compact, space-saving piping layouts.
2. Full size range from G1/8" to G2" (7B4-02 to 7B4-32) for flexible system integration.
3. Parallel BSP thread (G) with 60° cone sealing ensures a reliable, leak-tight connection.
4. Precision-machined carbon steel construction delivers high strength and long service life.
5. Widely used in hydraulic, pneumatic, oil and gas systems for smooth flow direction change at 45°
