THREAD DIMENSIONS PART NO. E A B 9N-02CAP Z1/8"X27 17.5 17 9N-04CAP Z1/4"X18 23 19 9N-06CAP Z3/8"X18 24 24 9N-08CAP Z1/2"X14 28 30 9N-12CAP Z3/4"X14 28 36 9N-16CAP Z1"X11.5 34 46 9N-20CAP Z1.1/4"X11.5 37 55 9N-24CAP Z1.1/2"X11.5 37 65 9N-32CAP Z2"X11.5 40.5 75
PEHEL/ NPT FEMALE PLUG
PEHEL Hydraulic Model: P9N-CAP
QTY:
NPT FEMALE PLUG
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: PLUG
Thread Type: NPT
About the item:
1. 9N‑CAP is hex‑style NPT female cap, designed for sealing male NPT threaded ports on hydraulic pipelines.
2. Tapered NPT internal thread conforms to ASME B1.20.1 standard, achieving reliable sealing with thread sealant.
3. Full size range covers Z1/8"‑Z2" NPT threads to match most American‑standard male‑thread hydraulic connectors.
4. Precisely‑machined carbon‑steel body with zinc‑plated finish, providing corrosion resistance and easy wrench installation.
5. Used for port blocking and thread protection, widely applied in industrial manifolds and mobile hydraulic equipment maintenance.
