THREAD DIMENSIONS PART NO. E F G A B C S1 AN-02 Z1/8"X27 Z1/8"X27 Z1/8"X27 21 21 21 11 AN-04 Z1/4"X18 Z1/4"X18 Z1/4"X18 25.5 25.5 25.5 14 AN-06 Z3/8"X18 Z3/8"X18 Z3/8"X18 31 31 31 19 AN-08 Z1/2"X14 Z1/2"X14 Z1/2"X14 36.7 36.7 36.7 22 AN-12 Z3/4"X14 Z3/4"X14 Z3/4"X14 44 44 44 27 AN-16 Z1"X11.5 Z1"X11.5 Z1"X11.5 50 50 50 33 AN-20 Z1.1/4"X11.5 Z1.1/4"X11.5 Z1.1/4"X11.5 54.5 54.5 54.5 41 AN-24 Z1.1/2"X11.5 Z1.1/2"X11.5 Z1.1/2"X11.5 59.5 59.5 59.5 48
PEHEL/NPT MALE TEE
PEHEL Hydraulic Model: PAN
QTY:
NPT MALE TEE
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: TEE
Thread Type: NPT MALE
ABOUT THE ITEM:
1. **NPT Male Tee** — American standard tapered pipe thread, equal three-way design for dependable branch connections.
2. **Full size range** from 1/8" to 1-1/2" (AN-02 to AN-24) to cover diverse piping needs.
3. **Precision-machined NPT threads** ensure a tight, leak-proof seal under high pressure.
4. **Compact forged construction** delivers high strength and long service life in tight spaces.
5. **Widely used** in hydraulic, pneumatic, oil and gas systems for safe, efficient flow distribution.
