Leak-Free Hydraulic Valve Subplate – PHS3A Series Oil Block Manifold, Carbon or Stainless Steel, Silver Zinc Plated, Custom OEM Ports
PEHEL Hydraulic Model: PHS3A...P
QTY:
- 1. Material: Carbon steel
2. Subplate, A-B-P-T on back, weigh 1 kg
Subplate, A-B-P-T on side 1/4”G, weigh 1 kg
3. up to 8 stations
4. NPT, SAE, PT thread for all parts is available
5. Superior in quality and competitive in price About the item:
1. Full Series Coverage – The PHS3A series subplate manifold spans multiple circuit sizes on one platform, so you can source every oil block manifold from a single qualified supplier.
2. Material Matched to Duty – Choose carbon steel for cost-effective general hydraulics or stainless steel for food processing, marine and chemical washdown environments.
3. Zinc-Plated Surface Protection – Silver zinc plating resists rust, oil and handling abrasion, keeping threads and sealing faces clean from storage through service life.
4. OEM Machining with Fast Turnaround – Port layout, thread standard and logo engraving produced to drawing, low MOQ, and every manifold block 100% pressure-tested before shipment.
5. Compact, Low-Loss Internals – Optimised internal drilling cuts pressure drop and external fittings, shrinking the hydraulic manifold footprint inside crowded control cabinets.
