PART NO. THREAD O-RING DIMENSIONS E F F A B L S1 1JO-04L 7/16"X20 7/16"X20 O904 35 9.14 50.5 14 1JO-05L 1/2"X20 1/2"X20 O905 37 9.14 52.5 17 1JO-06L 9/16"X18 9/16"X18 O906 39.5 9.93 55.5 17 1JO-08L 3/4"X16 3/4"X16 O908 48 11.13 67.5 22 1JO-10L 7/8"X14 7/8"X14 O910 53 12.7 76 27 1JO-12L 1.1/16"X12 1.1/16"X12 O912 63 15.1 89 32 1JO-16L 1.5/16"X12 1.5/16"X12 O916 72 15.1 100 38 1JO-20L 1.5/8"X12 1.5/8"X12 O920 88.1 15.1 118 50
Long JIC to ORB Adapter | 74° Cone Seal Male SAE O-Ring Male Fitting
PEHEL Hydraulic Model: P1JO-L
QTY:
Material:Carbon steel
Brand:Pehel, OEM
Color: Silver
Connector Type: Nipple
Thread Type: JIC, SAE O-RING BOSS
Surface Treatment: CR3+ White Zinc Plated
About the item:
1. Dual-Seal Reliability: Combines a JIC 74° cone seat with a SAE O-ring boss (ORB) face seal, providing superior leak-proof performance in high-pressure hydraulic circuits.
2. Extended Reach Design: The long male adapter body allows for deeper thread engagement and easier wrench access in recessed or hard-to-reach manifold ports.
3. Anti-Corrosion Finish: Coated with a durable silver zinc plating that protects the carbon steel core from rust, extending service life in corrosive environments.
4. High-Pressure Endurance: Built from heavy-duty materials to withstand extreme hydraulic pressures, making it ideal for industrial machinery and mobile equipment.
5. OEM Flexibility: Available under the Pehel brand or as custom OEM solutions, ensuring compatibility with your existing equipment specifications and drawings.
