PART NO. THREAD E HOSE BORE O RING DIMENSIONS DN DASH A S2 16011SW-08-06 3/4"X16 10 06 O908 45.5 24 16011SW-08-08 3/4"X16 12 08 O908 46 24 16011SW-10-08 7/8"X14 12 08 O910 49 27 16011SW-10-10 7/8"X14 16 10 O910 48.5 27 16011SW-12-12 1.1/6"X12 20 12 O912 54 32
SAE O-Ring Boss Swivel Male Connector, Carbon Steel & Stainless Steel, Zinc Plated
PEHEL Hydraulic Model: P16011SW
QTY:
Male SAE O-Ring Hydraulic Hose Fitting 16011
Material: Carbon steel, stainless steel
Brand: Pehel, OEM
Color: Silver color zinc plating
Connector Type:
Thread Type:
About the item:
- 1.SAE O-ring boss swivel male connector — carbon steel body for hydraulic tube connections.
- 2.Stainless steel swivel connector option for corrosion-resistant service in harsh environments.
- 3.Silver zinc plating protects the ORB swivel surface and extends service life.
- 4.Swivel design simplifies tube routing and allows easy alignment during installation.
- 5.Available under Pehel brand or OEM production for your connector sourcing needs.
- 6.Built for hydraulic tube lines in machinery, equipment, and fluid power systems.
