THREAD O-RING DIMENSIONS PART NO. E F F A L S1 5HN-10-02 M10X1 Z1/8"X27 O08.1X1.6 8.5 24 14 5HN-12-02 M12X1.5 Z1/8"X27 O09.3X2.4 11 26 17 5HN-12-04 M12X1.5 Z1/4"X18 O09.3X2.4 11 31.5 19 5HN-14-04 M14X1.5 Z1/4"X18 O11.3X2.4 11 31.5 19 5HN-16-06 M16X1.5 Z3/8"X18 O13.3X2.4 12.5 34.5 22 5HN-16-08 M16X1.5 Z1/2"X14 O13.3X2.4 12.5 40 30 5HN-18-06 M18X1.5 Z3/8"X18 O15.3X2.4 12.5 36.5 24 5HN-18-08 M18X1.5 Z1/2"X14 O15.3X2.4 12.5 41.5 30 5HN-22-08 M22X1.5 Z1/2"X14 O19.3X2.4 13 42.5 30 5HN-27-12 M27X2 Z3/4"X14 O23.5X3.0 18.5 47.5 36 5HN-33-16 M33X2 Z1"X11.5 O29.5X3.0 18.5 53.5 41 5HN-42-20 M42X2 Z1.1/4"X11.5 O38.5X3.0 16 52 50 5HN-48-24 M48X2 Z1.1/2"X11.5 O44.5X3.0 17.5 53 60
Pehel/5HN/Male Metric O-Ring Seal-Female NPT Straight Adapter/Sizes Available
PEHEL Hydraulic Model: P5HN
QTY:
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver Zinc plating
Connector Type: Straight
Thread Type: Metric O-ring/NPT
About the item:
1.Interchangeable with ISO 8434 standard counterparts, no custom modification required for direct replacement in existing hydraulic systems.
2.Full through-bore design maintains consistent internal flow diameter, avoiding flow restriction that causes system heat rise and efficiency loss3.Zinc-plated carbon steel body with salt spray resistance up to 240 hours, effectively preventing corrosion in outdoor and humid working environments.
