PART NO.
THREAD E
HOSE BORE
TUBE O.D.
DIMENSIONS
DN
DASH
C
S1
P10412-14-04
M14X1.5
6
4
8
13
17
-19
M14X1.5
8
5
8
13
17
-20
M16X1.5
6
4
10
13.5
17
-21
M16X1.5
8
5
10
13.5
17
-22
M16X1.5
10
6
10
13.5
17
-23
M18X1.5
8
5
12
13.5
19
-24
M18X1.5
10
6
12
13.5
19
-28
M20X1.5
12
8
14
13.5
22
-28
M22X1.5
10
6
15
13.5
24
-30
M22X1.5
12
8
15
13.5
24
-34
M26X1.5
12
8
18
14
27
-36
M26X1.5
16
10
18
14
27
-35
M27X1.5
12
8
18
14
30
-37
M27X1.5
16
10
18
14
30
-51
M32X2
20
12
22
18
32
-48
M36X2
20
12
28
18
38
-52
M36X2
25
16
28
18
38
-58
M42X1.5
25
16
33
19
46
-65
M45X2
32
20
35
19
46
-76
M52X2
40
24
42
19
55
Metric Male 24º Cone Seat L.T. Hydraulic Crimp Hose Connector
PEHEL Hydraulic Model: P10412
QTY:
Metric Male 24Degree Cone Seat L. T. DIN hydraulic hose fitting 10412
- Material: Carbon steel, stainless steel
- Brand: Pehel, OEM
- Color: Silver color zinc plating
- Connector Type: Light Type Crimp Hose Fitting
- Thread Type: Metric Male 24° Cone Seat Thread
- About the item:
- 1.Silver zinc‑plated hydraulic hose fitting achieves great corrosion resistance for long‑duration industrial usage
- 2.Precisely machined 24 degree cone seat ensures perfect sealing and leak‑free hydraulic hose assembly
- 3.Light‑weight light type hydraulic hose fitting features compact structure for limited‑space installation scenarios
- 4.This metric hydraulic hose adapter supports OEM customization to meet varied project specification requirements
- 5.Rigorous quality testing for every metric male 24º cone seat hose fitting, stable under high‑pressure working status
