PART NO. THREAD TUBE O.D. DIMENSIONS E F D A B S1 S2 5QN9-14-04 M14X1.5 Z1/4"X18 8 35.5 25 19 17 5QN9-16-06 M16X1.5 Z3/8"X18 10 39.5 27 24 19 5QN9-18-06 M18X1.5 Z3/8"X18 12 39.5 27 24 22 5QN9-22-08 M22X1.5 Z1/2"X14 14 44.5 31.5 30 27 5QN9-27-12 M27X.5 Z3/4"X14 18 45.5 34.5 33 32 5QN9-36-16 M36X2 Z1"X11.5 25 56 41.1 41 41 5QN9-42-20 M42X2 Z1.1/4"X11.5 32 66.5 43.2 50 50 Note: In case if you are interested to order the adapter in complete set with sleeve and nut ,it is necessory to inset suffix "RN" in after of part no., for example 5QN9-18-06RN
PEHEL / 90 METRIC MALE 74 CONE/NPT FEMALE ADPTER
PEHEL Hydraulic Model: 5QN9
QTY:
90 METRIC MALE 74 CONE/NPT FEMALE ADPTER
Material: Carbon steel
Brand: Pehel, OEM
Color: Silver
Connector Type: elbow
Thread Type 1: METRIC MALE 74 CONE
Thread Type 2: NPT FEMALE
About the item:
1. 90° Metric Male 74° Cone / NPT Female — hybrid adapter connecting metric tube systems to NPT ports.
2. Metric male thread with 74° cone seat ensures a reliable, leak-tight DIN-style seal.
3. NPT female end allows direct connection to American standard taper thread ports.
4. Available with sleeve and nut (add suffix "RN") for complete tube assembly.
5. Ideal for hydraulic and pneumatic systems needing compact metric-to-NPT conversion at 90°.
