PART NO. THREAD TUBE O.D. DIMENSIONS MPa E F D1 l1 L1 S1 S2 1CL-12-10 M12X1.5 M10X1 6 8.5 23 14 14 25 L 1CL-14-12 M14X1.5 M12X1.5 8 10 25 19 17 1CL-14 M14X1.5 M14X1.5 8 10 25 19 17 1CL-16-14 M16X1.5 M14X1.5 10 11 26 19 19 1CL-18-16 M18X1.5 M16X1.5 12 12.5 27 22 22 1CL-18-22 M18X1.5 M22X1.5 12 14 28.5 27 22 1CL-22-18 M22X1.5 M18X1.5 15 13.5 29 24 27 1CL-22 M22X1.5 M22X1.5 15 15 30.5 27 27 1CL-22-27 M22X1.5 M27X1.5 15 15 30.5 34 27 1CL-22-42 M22X1.5 M42X2 15 17 32.5 50 27 1CL-26-22 M26X1.5 M22X1.5 18 14.5 31 27 32 16 L 1CL-30-26 M30X2 M26X1.5 22 16.5 33 32 36 1CL-30-33 M30X2 M33X2 22 19.5 36 41 36 1CL-30 M30X2 M30X2 22 16.5 33 36 36 1CL-36-33 M36X2 M33X2 28 17.5 34 41 41 10 L 1CL-45-42 M45X2 M42X2 35 17.5 39 50 50 1CL-52-48 M52X2 M48X2 42 19 42 55 60 1DL-14-12 M14X1.5 M12X1.5 6 13 28 19 17 63 S 1DL-16-14 M16X1.5 M14X1.5 8 15 30 19 19 1DL-18-16 M18X1.5 M16X1.5 10 15 31 22 22 1DL-20-18 M20X1.5 M18X1.5 12 17 33 22 24 1DL-22-20 M22X1.5 M20X1.5 14 19 37 27 27 1DL-24-22 M24X1.5 M22X1.5 16 18.5 37 27 30 40 S 1DL-30-27 M30X2 M27X2 20 20.5 42 32 36 1DL-36-33 M36X2 M33X2 25 23 47 41 46 1DL-42-42 M42X2 M42X2 30 23.5 50 50 50 25 S 1DL-52-48 M52X2 M48X2 38 26 57 55 60 Note��In case if you are interested to order the adapter in complete set with cutting ring
PEHEL / 1CL-1DL / Hydraulic Adaptors Metric Male 24°cone Seat Ready to Ship
PEHEL Hydraulic Model: 1CL-1DL
QTY:
Hydraulic Adapters Metric Male Light Duty Heavy Duty Easier To Install
Material: Carbon steel
Surface Treatment: White Zinc Plating
Brand: PEHEL, OEM
Color: Silver
Connector Type: Straight
Thread: Metric
1. PEHE metric 24° cone elbow adapter is designed for leak-free hydraulic connections.
2. Carbon steel of good quality with zinc plating ensures superior durability and corrosion resistance.
3. Professional design delivers reliable sealing under high pressure and extreme temperatures.
4. Compatible with multiple fluid types, including oil, water, and air.
5. Metric male 24° cone prevents fluid escape in demanding industrial applications.
