PART NO. THREAD DIMENSIONS E F A B S1 7B9-02 G1/8"X28 G1/8"X28 20 20 16 7B9-04 G1/4"X19 G1/4"X19 22.5 22.5 19 7B9-06 G3/8"X19 G3/8"X19 26 26 24 7B9-08 G1/2"X14 G1/2"X14 31 31 27 7B9-12 G3/4"X14 G3/4"X14 34 34 33 7B9-16 G1"X11 G1"X11 42 42 41 7B9-20 G1.1/4"X11 G1.1/4"X11 48 48 50 7B9-24 G1.1/2"X11 G1.1/2"X11 53 53 60 7B9-32 G2"X11 G2"X11 62 62 70
PEHEL / 7B9 / Hydraulic Adapters BSP Fixed Elbow Adaptors Ready to Ship
PEHEL Hydraulic Model: 7B9
QTY:
BSP Female 90° Fixed Elbow Hydraulic Adapter – Carbon Steel High Pressure Pipe Fitting ISO 1179
Material: Carbon steel
Surface Treatment: White Zinc Plating
Brand: PEHEL, OEM
Color: Silver
Connector Type: 90°
Thread: BSP
1. PEHEL 7B9 BSP female 90° elbow adapter enables 90° directional changes in compact hydraulic systems with limited space.
2. Precision-engineered with 60° cone sealing seats ensuring leak-free connections under high working pressures.
3. Manufactured from high-grade carbon steel with corrosion-resistant plating for long-lasting durability in harsh environments.
4. ISO 1179 standard-compliant BSP parallel female threads guarantee reliable compatibility with standard hydraulic components.
5. Ready to ship with fast delivery, ideal for engineering machinery, mining, agriculture, and mobile hydraulic applications
